If you’re searching for a Bradford White 80 gallon electric water heater, you may have noticed that the search results don’t point to just one product. Bradford White offers 80-gallon electric options across different applications and configurations, including commercial ElectriFLEX models and 80-gallon AeroTherm hybrid heat pump models.
That means the real question isn’t simply, “Which 80-gallon heater should I buy?” It’s which model, power configuration, and heater type actually fit your hot-water demand, electrical service, available space, and application?
Bradford White’s 80-gallon electric lineup is not one universal model. The right choice depends on whether you need a standard electric, light- or medium-duty commercial heater, heavy-duty commercial ElectriFLEX HD equipment, or an 80-gallon AeroTherm heat pump water heater. Before ordering, verify the exact model, voltage, phase, kW input, dimensions, recovery requirements, and installation conditions.
Bradford White 80 Gallon Electric Water Heater Options
The phrase “Bradford White 80 gallon electric water heater” can refer to more than one type of equipment. Bradford White’s commercial electric range includes multiple capacities, voltages, wattages, and phase configurations, while its AeroTherm hybrid electric heat pump line includes an 80-gallon model as well. :contentReference[oaicite:0]{index=0}
Bradford White identifies ElectriFLEX LD as a light-duty commercial line, ElectriFLEX MD as a medium-duty option, and ElectriFLEX HD as a heavy-duty commercial line designed for applications such as large restaurants, health clubs, stadiums, and schools. Its current AeroTherm G2 range includes 50-, 65-, and 80-gallon capacities. :contentReference[oaicite:1]{index=1}
Bradford White 80 Gallon ElectriFLEX HD: What You Should Know
If your search is specifically for an 80 gallon Bradford White commercial electric water heater, the ElectriFLEX HD is one of the most important models to understand.
Bradford White’s official specification sheet identifies the CEHD80 family as an 80-gallon nominal-capacity commercial electric model. The specification sheet lists a 6–54 kW input range for the CEHD80 configuration family, while the exact available configuration depends on the model designation and electrical setup. :contentReference[oaicite:2]{index=2}
Key CEHD80 specifications
- Nominal tank capacity: 80 gallons
- US Imperial capacity listed by Bradford White: 67 gallons
- kW input range: 6–54 kW for the CEHD80 family
- Jacket diameter: 26 inches
- Floor-to-top height: approximately 61¼ inches
- Floor-to-hot-water connection: approximately 65½ inches
- Standard water connection: 1½-inch NPT
- Approximate shipping weight: 335 lb for the listed standard configuration, with an ASME version listed at 378 lb
These dimensions and weights come from Bradford White’s specification sheet and should not be treated as universal measurements for every Bradford White 80-gallon electric model. Always verify the exact model number and current specification sheet before ordering. :contentReference[oaicite:3]{index=3}
Why kW, Voltage and Phase Matter
One of the biggest mistakes you can make when comparing an 80-gallon electric water heater is to look only at tank size.
An 80-gallon tank tells you how much water the storage tank holds. It does not by itself tell you how quickly the heater can recover hot water or whether its electrical requirements match your building.
What does kW mean?
kW refers to the heater’s electrical power input. In general, a higher heating input can provide greater heating capacity and recovery potential, but you cannot simply choose the largest kW number. The electrical service, application, controls, wiring, breaker requirements and exact manufacturer configuration all have to be compatible.
Why does voltage matter?
Electric water heaters are designed for specific electrical configurations. Bradford White’s commercial ElectriFLEX range is available in multiple voltage, wattage and phase configurations, which is why the exact model designation matters when replacing an existing unit. :contentReference[oaicite:4]{index=4}
What does phase mean?
Single-phase and three-phase electrical systems are not interchangeable simply because the tank capacity is the same. Your building’s existing electrical service and the heater’s required configuration must be checked before purchase.
Important:
Do not choose an 80-gallon electric heater by kW, voltage or phase based only on a product listing. Have the existing electrical service, water connections, demand and installation requirements checked by a qualified professional before ordering.
Hydrojet, Vitraglas and Other Bradford White Features
If you’ve searched for a Bradford electric water heater or specifically a Hydrojet water heater, you’ll often see these technologies mentioned in Bradford White product information.
Hydrojet Total Performance System
Bradford White says its Hydrojet Total Performance System is designed to reduce sediment buildup in the tank. Sediment can affect water-heater performance and efficiency, so reducing buildup is an important part of the system’s design. :contentReference[oaicite:5]{index=5}
Vitraglas tank lining
Bradford White uses Vitraglas tank lining in its ElectriFLEX commercial products. The manufacturer describes the lining as providing added tank protection. :contentReference[oaicite:6]{index=6}
Microban antimicrobial protection
The ElectriFLEX commercial range also uses Microban antimicrobial product protection on the tank lining. Bradford White states that this is intended to help prevent the growth of bacteria, mold and mildew on the surface of the tank lining. :contentReference[oaicite:7]{index=7}
INCOLOY heating elements
Bradford White’s commercial electric water-heater information describes immersed INCOLOY elements that transfer heat directly to the water. The exact element configuration should still be checked against the model and specification sheet you are purchasing. :contentReference[oaicite:8]{index=8}
Is an 80-Gallon Bradford White Electric Water Heater Right for You?
This is where I would focus most of your attention. Bigger does not automatically mean better.
An 80-gallon heater may make sense when your hot-water demand justifies the storage capacity, but the best solution depends on your application and recovery requirements.
Use this decision framework
- Identify the application. Is it a home, office, restaurant, salon, school, health club, or another commercial facility?
- Estimate peak hot-water demand. Consider when multiple fixtures or users need hot water at the same time.
- Check the existing electrical service. Verify voltage, phase and available electrical capacity.
- Compare recovery requirements. A tank’s storage capacity is only part of the sizing equation.
- Measure the installation area. Check height, diameter, connections and service access.
- Confirm the exact model. Do not order from the phrase “80 gallon” alone.
- Review installation and code requirements. A professional should verify the complete installation before purchase.
Residential vs. Commercial: Which One Do You Need?
This distinction is especially important for this keyword because many of the visible Bradford White 80-gallon electric results are commercial products.
Bradford White describes its ElectriFLEX LD products for light-duty commercial applications, its MD products for medium-duty applications such as beauty salons, small restaurants and offices, and its HD products for larger commercial hot-water demands. :contentReference[oaicite:9]{index=9}
If you are shopping for a home rather than a commercial building, don’t assume a commercial ElectriFLEX model is automatically the right replacement. Bradford White also offers residential electric and hybrid heat-pump products, including an 80-gallon AeroTherm G2 model. :contentReference[oaicite:10]{index=10}
Before you buy:
First decide whether you need a residential electric heater, commercial light-duty/medium-duty equipment, heavy-duty commercial equipment, or a hybrid heat-pump water heater. That decision can eliminate the wrong products before you start comparing prices.
Bradford White 80 Gallon Electric Water Heater Dimensions
Dimensions are one of the most useful details to check before purchasing because an 80-gallon tank is a substantial piece of equipment.
For the CEHD80 ElectriFLEX HD family, Bradford White’s specification sheet lists a 26-inch jacket diameter and approximately 61¼ inches from the floor to the top of the heater. Other connection dimensions are model-specific and should be checked on the current specification sheet. :contentReference[oaicite:11]{index=11}
Do not use the CEHD80 dimensions as the dimensions for every Bradford White 80-gallon water heater. An AeroTherm heat pump model, for example, has a different physical design and installation requirements.
How Much Does a Bradford White 80 Gallon Electric Water Heater Cost?
There isn’t one reliable price for every Bradford White 80-gallon electric water heater.
The price can vary according to the exact model, heating input, voltage, phase, commercial or residential configuration, distributor, availability, accessories and installation requirements.
Think about total installed cost
Your project cost may include:
- The water heater itself
- Professional installation
- Electrical modifications, if required
- Plumbing modifications or replacement components
- Required valves, fittings or accessories
- Permits or code-related work where applicable
- Removal and disposal of the old heater
That is why comparing a product-page price alone can give you an incomplete picture of what an 80-gallon replacement will actually cost.
80 Gallon vs. 50 Gallon Bradford White Electric Water Heater
If you’re also comparing a 50 gallon electric Bradford White water heater, don’t choose based only on the idea that 80 gallons is “better.” The correct size depends on demand.
If you’re unsure whether you need 50, 65, 75, or 80 gallons, size the system around actual hot-water demand rather than choosing the largest tank that will fit.
What About the Bradford White 80 Gallon AeroTherm?
If energy efficiency is one of your main priorities, the Bradford White AeroTherm deserves a separate look.
Bradford White’s current AeroTherm G2 hybrid electric heat pump water heater is available in 50-, 65-, and 80-gallon capacities. The 80-gallon G2 model is identified as RE2HP8010, while connected configurations are also listed by the manufacturer. :contentReference[oaicite:12]{index=12}
A heat-pump water heater works differently from a conventional resistance electric storage heater, so it should not be compared only by tank size. Available space, installation conditions, operating environment, efficiency goals and the manufacturer’s requirements all matter.
Good rule:
If you’re comparing a conventional Bradford White electric heater with an AeroTherm heat pump model, compare the whole system and installation requirements, not just the 80-gallon capacity.
What Should You Check Before Ordering?
- Exact model number: Confirm the complete model rather than ordering by tank capacity alone.
- Application: Confirm residential, light-duty commercial, medium-duty commercial, heavy-duty commercial, or heat-pump use.
- Voltage: Verify that the heater matches the building’s electrical service.
- Phase: Confirm single-phase or three-phase requirements where applicable.
- kW input: Make sure the heating input is appropriate for the application and electrical system.
- Dimensions: Check height, diameter, connection locations and service clearance.
- Recovery: Make sure the system can meet your expected peak hot-water demand.
- Connections: Verify water connection sizes and locations.
- Installation requirements: Check local code, electrical, plumbing and safety requirements.
- Warranty: Confirm the warranty for the exact model you are purchasing.
Maintenance and Replacement Considerations
Even a well-designed water heater still needs appropriate maintenance. Sediment, heating-element problems, anode condition, temperature-control issues, leaks and electrical faults can all affect performance.
Bradford White’s replacement-parts documentation for the CEHD80 family lists components such as heating elements, thermostats, anodes, temperature-and-pressure relief valves, drain valves and other service parts. :contentReference[oaicite:13]{index=13}
If your existing unit is leaking, repeatedly tripping electrical protection, producing inadequate hot water, or showing other serious faults, have it professionally inspected rather than assuming that replacing one component will solve the problem.
Common Mistakes When Buying an 80-Gallon Electric Water Heater
- Assuming every 80-gallon model is the same. They are not.
- Choosing the highest kW available. Bigger electrical input is not automatically better for your building.
- Ignoring voltage and phase. The tank can be the correct size and still be the wrong electrical configuration.
- Comparing only product prices. Installation can materially change the total project cost.
- Ignoring recovery requirements. Storage capacity alone does not tell the whole story.
- Skipping the dimensions. An 80-gallon heater needs adequate installation and service space.
- Buying a commercial model for a residential application without checking suitability.
- Using specifications from one model for another model. Always verify the exact model documentation.
Frequently Asked Questions
Is there a Bradford White 80 gallon electric water heater?
Yes. Bradford White offers multiple 80-gallon electric-water-heater options, including commercial ElectriFLEX configurations and 80-gallon AeroTherm hybrid heat-pump models. The correct product depends on the application and exact configuration. :contentReference[oaicite:14]{index=14}
What is the Bradford White 80 gallon ElectriFLEX HD model?
The ElectriFLEX HD CEHD80 is an 80-gallon commercial electric water-heater family designed for high-demand applications. Bradford White lists the HD line for large restaurants, health clubs, stadiums, schools and other applications requiring large volumes of hot water. :contentReference[oaicite:15]{index=15}
What kW options are available for the Bradford White CEHD80?
Bradford White’s specification sheet lists a 6–54 kW input range for the CEHD80 family. The correct kW configuration depends on the exact model, voltage, phase and application, so you should verify the current specification sheet before ordering. :contentReference[oaicite:16]{index=16}
What is Hydrojet on a Bradford White water heater?
Hydrojet is Bradford White’s Total Performance System, which the manufacturer says is designed to reduce sediment buildup in the tank. :contentReference[oaicite:17]{index=17}
How much does an 80 gallon Bradford White electric water heater cost?
There is no single price for every 80-gallon Bradford White electric heater. Pricing varies according to the exact model, kW input, voltage, phase, distributor, availability and installation requirements. Compare the complete installed cost rather than one product-listing price.
What are the dimensions of the Bradford White CEHD80?
Bradford White’s CEHD80 specification sheet lists a 26-inch jacket diameter and approximately 61¼ inches from the floor to the top of the heater. Connection dimensions are also listed in the manufacturer’s specification sheet. Always verify the exact model before installation. :contentReference[oaicite:18]{index=18}
Is an 80-gallon water heater better than a 50-gallon model?
Not necessarily. An 80-gallon model provides more storage, but the right size depends on hot-water demand, recovery requirements, available space, installation conditions and the specific application.
Does Bradford White make an 80-gallon heat pump water heater?
Yes. Bradford White’s current AeroTherm G2 hybrid electric heat pump line includes an 80-gallon model. The manufacturer lists the 80-gallon G2 model as RE2HP8010. :contentReference[oaicite:19]{index=19}
Can I replace my old water heater with any Bradford White 80-gallon model?
No. You should match the new heater to the application, electrical service, hot-water demand, dimensions, plumbing connections and applicable installation requirements. A professional should verify compatibility before the purchase is finalized.
A Bradford White 80 gallon electric water heater can be an excellent solution when the tank size and exact configuration match your application. But “80 gallons” is only the starting point.
Before buying, compare the model, application, kW input, voltage, phase, recovery requirements, dimensions, installation requirements and total cost. That approach will help you avoid buying an 80-gallon heater that looks right on paper but is not the right fit for your property.
Need Help Choosing or Replacing an 80-Gallon Water Heater?
If you’re replacing an existing water heater in Miami, the safest approach is to have the current unit, electrical setup, plumbing connections, available space and hot-water demand evaluated before selecting the replacement.
For related information, you can also review our water heater replacement service and explore our complete plumbing services.
Not Sure Which Water Heater You Need?
Get the right replacement by having the existing system and installation requirements checked before you order.
Related Resources
- Bradford White Commercial Electric Water Heaters — manufacturer information on ElectriFLEX commercial electric water heaters.
- Bradford White ElectriFLEX HD Specification Sheet — detailed technical specifications for the commercial ElectriFLEX HD family.
- Bradford White AeroTherm Heat Pump Water Heaters — manufacturer information on the 50-, 65-, and 80-gallon AeroTherm range.
- Bradford White 80-Gallon Commercial Electric Water Heater at Ferguson — useful for reviewing one specific commercial configuration.
- Bradford White ElectriFLEX HD 80-Gallon Product Listing — another reference for a specific CEHD80 configuration.
Note: Product specifications, model availability and pricing can change. Always verify the current manufacturer documentation and exact model before purchasing or installing a water heater.
